Features:

• Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
• Max 320Mbps Incoming Bandwidth
• Up to 12MP Resolution for Preview and Playback
• HDMI/VGA simultaneous video output
• 1-8 PoE Ports Support 800m ePoE & EoC

Binding: Electronics

model number: NVR5216-16P-4KS2E

Part Number: NVR5216-16P-4KS2E

Details: System Main Processor:Quad-core embedded processor Operating System:Embedded LINUX Display Interface:1 HDMI, 1 VGA Resolution:HDMI: 3840 × 2160 , 1920 × 1080 , 1280 × 1024,1280 × 720 , 1024 × 768 ; VGA: 1920 × 1080 , 1280 × 1024,1280 × 720 , 1024 × 768 Decoding Capability:4-ch@8MP(30fps), 16-ch@1080P(30fps) Multi-screen Display:16CH: 1/4/8/9/16 ; 32CH: 1/4/8/9/16/25/36 OSD:Camera title, Time, Camera lock, Motion detection, Recording Third-party Support Third-party Support:Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more Audio and Video IP Camera Input:16 Channel Two-way Talk :1 Channel Input, 1 Channel Output, RCA Recording Compression: Smart H.265+/H.265/Smart H.264+/H.264/MJPEG Resolution: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1 etc. Bit Rate:16Kbps ~ 20Mbps Per Channel Record Mode:Manual, Schedule (Regular, MD(Motion Detection) , Alarm, IVS), Stop Record Interval:1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec Network Interface:1 RJ-45 Ports (10/100/1000Mbps) PoE:16 ports (IEEE802.3af/at) ; 1-8 ports support ePoE & EoC Network Function:HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4IP Max. User Access:128 users Smart Phone:iPhone, iPad, Android Interoperability:ONVIF 2.4, SDK, CGI Electrical Power Supply:Single, AC100V ~ 240V, 50 ~ 60 Hz Power Consumption:NVR: <15.2W (Without HDD) ; PoE: Max 25.5W for single port 130W total rated power, 80% control for protection Fan : Smart fan, automatically adjust running speed

EAN: 0653437211749

Package Dimensions: 17.5 x 16.5 x 6.5 inches
